Robust casing ensures device reliability, protection, and extended operational longevity.
Maintains record of duty status and calculates hours of service for efficient operations.
Integrated CAN protocol for efficient data communication and system integration.
| GNSS Antenna | Internal High Gain |
| GSM Antenna | Internal High Gain |
| Indicators | 3 LED's (Power, GSM, GNSS) |
| SIM | Micro SIM |
| USB | 2.0 Micro USB |
| Memory | 6,000 Log Packets |
| GNSS | GPS, GLONASS, QZSS, BeiDou, GAGAN |
| Channels | 22 Tracking / 66 Acquisition Channel |
| Horizontal Position Autonomous | < 2.5m CEP |
| Tracking Sensitivity | -165dBm |
| Velocity | < 0.1m/s |
| Hot Start | < 1 sec |
| Warm Start | < 30 sec |
| Cold Start | < 35 sec |
| Hot Start | < 1sec |
| Warm Start | < 5sec |
| Cold Start | < 15sec |
| Technology | GSM |
| 2G Band | 850/900/1800/1900 MHz |
| RF Power | Class 4 (2W@850/900MHz), Class 1 (1W@1800/1900MHz) |
| Legislated OBD-II Protocol | ISO 15765-4, ISO 14230-4, ISO 9141-2, SAE J1850 VPW, SAE J1850 PWM |
| Non-Legislated OBD Protocol | ISO 15765, ISO 11898 (RAW CAN), SAE J1939 |
| Data Transfer | GPRS Multi-Slot Class 12 |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | SMS (text/data) |
| Voltage Range | 8-36V DC |
| Battery | 300mAh Li-Po 3.7V |
| Operating Temperature | - |
| Operating Humidity | - |
| Working Current | Sleep Mode < 5mA, Active Mode < 125mA |
| Operating Temperature | - |
| Operating Humidity | - |
| Specification | BT 4.0 |
