Advanced CAT 1 tracking device with 4G LTE and dependable 2G backup for reliable connectivity.
High voltage range enables extended operation and enhanced performance efficiency.
Seamlessly connect for real-time vehicle data monitoring and diagnostics with built-in CAN port.
| Digital Input | 3 |
| Digital Output | 2 |
| Analog Input | 1 |
| 1-Wire/1-RPM | 1 |
| CAN | 1 |
| RS232 | 1 |
| GNSS Antenna | Internal High Gain GNSS |
| LTE Antenna | Internal High Gain LTE |
| Indicators | 3 LED's (Power, GSM, GNSS) |
| SIM | Micro SIM |
| USB | 2.0 Micro USB |
| Memory | 64 Mb |
| CAN Support | All legislated OBD-II Protocols, Non-Legislated OBD Protocols & Heavy-Duty |
| GNSS | GPS, GLONASS, GALILEO, BeiDou, QZSS |
| Channels | 47 Tracking Channels |
| Horizontal Position Autonomous | <2.0m CEP |
| SBAS | Supported |
| Tracking Sensitivity | -166 dBm |
| Re acquisition Sensitivity | -147 dBm |
| Velocity | 0.1m/s |
| Hot Start | <2 sec |
| Warm Start | <25 sec |
| Cold Start | <30 sec |
| Technology | LTE CAT1, GSM |
| 4G Band | EU: LTE FDD:B1/B3/B5/B7/B8/B20/B28, NA: LTE FDD: B2/B3/B4/B5/B7/B8/B28/B66, AS: LTE FDD: B1/B3/B5/B8, LTE TDD: B34/B38/B39/B40/B41 |
| 2G Band | EU: 850/900/1800/1900 MHz, NA: 850/900/1800/1900 MHz, AS:900/1800 MHz |
| RF Power | EU & NA: GSM850/EGSM900: Class 4 (33 dBm ±2 dB), DCS1800/PCS1900: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB), AS: EGSM900: Class 4 (33 dBm ±2 dB), DCS1800: Class 1 (30 dBm ±2 dB), LTE-FDD: Class 3 (23 dBm ±2 dB), LTE-TDD: Class 3 (23 dBm ±2 dB) |
| Coding Scheme | CS 1, 2, 3, 4 |
| SMS | Point to point MO & MT, SMS cell broadcast |
| Voltage Range | 9-90V DC |
| Battery | 260mAh Li-Po 3.7V |
| Specification | BLE 5.0 |
| Supported Peripherals | Universal BLE sensors support, Beacons |
| Working Current | Sleep Mode < 25mA, Active Mode < 180mA @ 12V |
| Operating Temperature | -30 °C to +80 °C (without battery), -20 °C to +60 °C (with battery) |
| Operating Humidity | 5% to 95% non-condensing at +40 °C |
| Ingress Protection Rating | IP54 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature | -20 °C to +45 °C for 1 month, -20 °C to +35 °C for 6 months |
| Dimensions | 87 x 44 x 14 mm (LxBxH) |
| Weight | 71 g (Approx) |
