KEY FEATURES | |
IO | Digital Input: 3, Digital Output: 1, Analog Input: 2 |
GNSS & GPS Antenna
|
Internal High Gain Antenna
|
Indicators
|
3 LED's (Power, GSM, GPS)
|
SIM
|
Micro SIM |
Memory
|
10,000 Log Packets |
Support | Accelerometer Support |
POWER | |
Voltage Range | 8-36V DC |
Battery | 1000mAh Li-Po 3.7V |
NAVIGATION | |
GNSS | GPS, QZSS, BeiDou, GAGAN |
Channels | 22 Tracking / 66 Acquisition Channel |
Sensitivity | -165dBm |
Acceleration Accuracy | 0.1 m/s2 |
Velocity Accuracy | < 0.1m/s (within +/- 15% error) |
Hot Start | < 1sec |
Warm Start | < 30sec |
Cold Start | < 31sec |
CELLULAR NETWORK | |
Band | 2G Band: 850/900/1800/1900 MHz |
RF Power | Class 4 (2W@850/900 MHZ), Class 1 (1W@1800/1900 MHz) |
Coding Schemes | CS 1, 2, 3, 4 |
SMS
|
Point to point MO & MT, SMS cell broadcast
|
OPERATING ENVIRONMENT | |
Working Current | Sleep mode < 5mA, Active mode < 125mA |
Operating Temperature |
-10°
C to +80°
C
|
Humidity | 5% to 95% non-condensing at +40°C |
